Lexmark Optra W810 - Finisher Tray Drive Service Check (994); Finisher Shift Plate Drive Service Check (995); Finisher Paper Aligning Service Check (996)

2-54 Service Manual
4023-001
Finisher Tray Drive Service Check (994)
Finisher Shift Plate Drive Service Check (995)
Finisher Paper Aligning Service Check (996)
FRU Action
1 Finisher tray You may have a finisher tray drive problem. Check
the finisher tray for damage or binds. Replace if
necessary.
2 Finisher Tray
Home Sensor
PC2
Check the finisher tray home sensor (PC2) for
operation. Replace if defective.
3 • Finisher
Tray Motor
Belt
• Finisher
Tray Motor
(M8)
• Finisher
Main Board
PWB-A
The finisher tray motor belt may be broken.
Replace if damaged. Ensure connectors are
plugged in. The finisher tray motor may be
defective. Replace if it fails to turn. If problem
persists, replace the finisher main board PWB-A.
FRU Action
1 • Shift Plate
• Gears
•Belt
The shift plate may be damaged. Check for binds
or damaged gears. The drive belt may be broken.
Replace as necessary.
2 Shift Plate
Sensor (PC6)
The shift plate sensor PC6 may be defective.
Replace if necessary.
3 Shift Plate
Motor (M5)
The shift plate motor (M5) may be defective. If the
motor fails to start during POR replace it.
4 Finisher Main
Board PWB-A
If the motor turns during POR, replace the finisher
main board PWB-A.
FRU Action
1 CD Aligning
Home Sensor
(PC5)
You may have a paper aligning failure. Check the
CD aligning home sensor (PC5), replace if
defective.
