Parts Catalog 7-27
4023-001
Assembly 9: Printer Electrical Components
Ref
Part
Number
Units Description
9-1 12G2351 1 Lid
-2 12G2352 2 Shoulder Screw
-3 12G2353 1 Shield
-4 12G2354 1 Cover
-5 12G2355 1 Bracket
-6 12G2356 1 Shield Box
-7 12G2357 1 Reinforce Plate
-8 12G2358 1 Label Caution
-9 12G2359 1 Fuse 3.15A
-10 12G2360 1 Fuse 15A
-10 12G2361 1 Fuse 8A
-11 12G2362 1 Fuse 10A
-11 12G2363 1 Fuse 6.3A
-12 12G2364 1 Bracket
-13 12G2365 1 Power Supply, 110V, PU1
-13 12G2366 1 Power Supply, 220V, PU1–
below SN 1W856776
-13 12G3457 1 Power Supply, 220V, PU1–above SN 1W856776
NS 12G3456 1
Power Supply Resistor, 220V–above SN 1W856776
-14 12G2367 2 PWB Support 6.4h
-15 12G2368 1 PWB Support
-16 12G2369 1 Bracket
-17 12G2370 1 Printhead Asm
-18 12G2371 1 Bracket
-19 1 IC, PWB-A
Note: Included on PWB-A board only. Order
12G2374.
-20 12G2373 2 Fuse 3A
-21 12G2374 1
PWB-A, Printer Main Engine Board, 110V–all printers;
220V– below SN 1W856776
-21 12G3458 1
PWB-A, Printer Main Engine Board, 220V–above SN
1W856776
-22 12G2375 1 Harness
-A 1 Parts Packet 1, PN 12G3400
-B 1 Parts Packet 2, PN 12G3401
