Parts Catalog 7-53
4023-001
Assembly 18: Duplex Unit
Ref
Part
Number
Units Description
18-1 12G2494 1 Lever
-2 12G2495 1 Pressure Spring
-3 12G2496 1 Cover
-4 12G2497 2 Pressure Spring
-5 12G2498 2 Polyester Film
-6 12G2499 1 Stopper
-7 12G2500 1 Polyester Film
-8 12G2501 2 Roller
-9 12G2502 4 Roll
-10 12G2503 2 Shoulder Screw
-11 12G2504 1 Cover
-12 12G2505 1 Seal
-13 12G2190 4 Bushing
-14 12G2506 2 Gear 20 T
-15 12G2507 1 Tension Spring
-16 12G2508 1 Lever
-17 12G2509 1 Gear 12/40 T
-18 12G2510 1 Axle Plate
-19 12G2511 2 Motor, M1, M2 Duplex Drive
-20 12G2512 1 PWB-A, Duplex Control Board
-21 12G2513 1 Plate
-22 12G2514 2 Plate
-23 12G2515 3 Gear 35 T
-24 12G2516 2 Gear 24 T
-25 12G2517 1 Gear 17/45 T
-26 12G2518 1 Harness
-27 12G2519 1 Holder
-28 12G2520 4 Spring
-29 12G2081 1 Photo Interrupter, S2 Door Close
-30 12G2102 1 Stopper
-31 12G2521 1 Actuator
-32 12G2523 1 Torsion Spring
-33 12G2524 1 Frame
