Parts Catalog 7-107
4023-001
Assembly 34: Finisher/Mailbox Horizontal Transfer (A)
Ref
Part
Number
Units Description
34-1 12G2967 1 Cover
-2 12G2968 1 Bracket
-3 12G2969 1 Tension Spring
-4 12G2970 2 Roll
-5 12G2971 2 Bushing
-6 12G2972 1 Lever
-7 12G2973 1 Solenoid, Switch SL1
-8 12G2974 2 Seal
-9 12G2975 2 Magnet Catch
-10 12G2976 1 Cover
-11 12G2977 1 Handle
-12 12G2978 2 Plate
-13 12G2979 1 Rear Cover
-14 12G2980 1 Cushion
-15 12G2981 1 Guide Plate
-16 12G2982 1 Lower Cover
-17 12G2983 1 Shoulder Screw
-18 12G2984 1 Lever
-19 12G2985 4 Cushion
-20 12G2986 1 Torsion Spring
-21 12G2987 1 Guide Plate
-22 12G2988 1 Guide Plate
-A 1 Parts Packet 1, PN 12G3400
-C 1 Parts Packet 3, PN 12G3402
-D 1 Parts Packet 4, PN 12G3403
-E 1 Parts Packet 5, PN 12G3404
-F 1 Parts Packet 6, PN 12G3405
-G 1 Parts Packet 7, PN 12G3406
