Parts Catalog 7-97
4023-001
Assembly 31: Finisher Elevator Tray
Ref
Part
Number
Units Description
31-1 12G3250 1 Tray
-2 12G3251 2 Shaft
-3 12G3252 4 Pulley
-4 12G2971 2 Bushing
-5 12G3253 1 Bracket
-6 12G3254 3 Ball Bearing
-7 12G3255 1 Gear 35/75t
-8 12G3256 1 Reinforce Plate
-9 12G3257 1 Gear 60t
-10 12G3258 1 Gear 28/42t
-11 12G3259 1 Timing Belt
-12 12G3260 1 Bracket
-13 12G3261 1 PWB-Motor, Elevator M9
-14 12G3262 1 Shaft
-15 12G3263 1 Pulley 29t
-16 12G3264 2 Pulley
-17 12G3265 1 Actuator
-18 12G3266 3 Microswitch, S2, S3, S5
-19 12G3267 2 Tension Spring
-20 12G3268 2 Wire
-21 12G3269 2 Torsion Spring
-22 12G3270 1 Bracket
-23 12G3271 1 Bracket
-24 12G3460 2 Photo Interrupter, PC8, PC11
-25 12G3272 1 Actuator
-26 12G3273 2 Shaft
-27 12G3274 4 Bush
-28 12G3275 1 Bracket
-29 12G3276 1 Label
-30 12G3277 1 Shaft
-31 12G3278 1 Bracket
-32 12G3279 1 Lever
-33 12G3280 1 Torsion Spring
To Next Page
