Parts Catalog 7-77
4023-001
Assembly 26: Finisher Frames
Ref
Part
Number
Units Description
26-1 12G3062 1 Holder
-2 12G3063 1 Bracket
-3 12G3064 1 Bracket
-4 12G3065 1 PW Board-F, PWB-F
-5 12G3066 1 Bracket
-6 12G3067 1 Guide
-7 12G3068 1 Bracket
-8 12G3069 1 Microswitch, S4 Staple Door
-9 12G3070 1 Harness
-10 12G2949 1 Cord Bushing
-11 12G2951 1 Cord Bushing
-12 12G3071 1 Guide Plate
-13 12G3072 1 Harness
-14 12G3073 1 Harness
-15 12G3074 1 IC, PWB-A IC3
-16 12G3075 1 PWB-A, Control Board
-17 12G3076 6 PWB Support
-18 12G3077 4 PWB Support 12.7h
-19 12G3078 1 Mounting Plate
-20 12G3079 1 Harness
-21 12G3080 1 Plate
-22 12G3081 2 PWB-E, LED Board
-23 12G3082 4 Collar
-24 12G2859 2 Caster
-25 12G3083 2 Mounting Plate
-26 12G2858 2 Adjusting Bolt
-27 12G3084 2 Bracket
-28 12G3085 1 Plate Spring
-29 12G3086 2 Bracket
-30 12G3087 2 Caster
-31 12G2863 2 Stopper
-32 12G2865 1 Pipe
-33 12G2834 1 Holder
To Next Page
