Lexmark Optra W810 - Assembly 27: Finisher Paper Transport (A)

Parts Catalog 7-81
4023-001
Assembly 27: Finisher Paper Transport (A)
Ref
Part
Number
Units Description
27-1 12G3103 4 Plate Spring
-2 12G2907 4 Roll
-3 12G3104 2 Magnet Catch
-4 12G3105 1 Guide
-5 12G3106 1 Photo Interrupter, PC1
-6 12G3069 1 Upper Cover, S1
-7 12G3107 1 Bracket
-8 12G3108 1 Cover
-9 12G3109 1 Shoulder Screw
-10 12G3110 4 Plate Spring
-11 12G3111 1 Plate Spring
-12 12G2931 4 Roll
-13 12G3112 1 Roll
-14 12G3113 1 Polyester Film
-15 12G3114 1 Neutralizing Brush
-16 12G3115 1 Actuator
-17 12G3116 1 Torsion Spring
-18 12G3117 1 Guide Plate
-19 12G3118 1 Arm
-20 12G3119 1 Shaft
-21 12G3120 1 Torsion Spring
-22 12G3121 1 Cam
-23 12G3122 1 Plate Spring
-24 12G3123 1 Shoulder Screw
-25 12G2173 1 Stopper
-B 1 Parts Packet 2, PN 12G3401
-C 1 Parts Packet 3, PN 12G3402
-D 1 Parts Packet 4, PN 12G3403
-E 1 Parts Packet 5, PN 12G3404
-F 1 Parts Packet 6, PN 12G3405
-G 1 Parts Packet 7, PN 12G3406
