Parts Catalog 7-35
4023-001
Assembly 12: Printer Paper Tray
Ref
Part
Number
Units Description
12-1 12G2447 2 Stopper Ring
-2 12G2448 1 Shaft
-3 12G2449 2 Pressure Spring
-4 12G2450 1 Separator, Paper
-5 12G2451 1 Cleaning Pad
-6 12G2452 1 Pressure Spring
-7 12G2453 1 Polyester Film
-8 12G2454 2 Bushing
-9 12G2455 1 Pressure Spring
-10 12G2456 1 Joint
-11 12G2457 1 Lock Lever
-12 12G2458 1 Friction Sheet
-13 12G2459 1 Regulating Plate
-14 12G2460 1 Label Max Level
-15 12G2461 1 Regulating Plate
-16 12G2462 1 Lifting Plate
-17 12G2463 1 Width Scale
-18 12G2464 2 Rack Gear
-19 12G2465 1 Gear 20t
-20 12G2466 1 Lever
-21 12G2467 1 Regulating Plate
-22 12G2468 1 Length Scale
-23 12G2469 1 Label Paper Loading
-24 12G2470 1 Cassette Body
-25 12G2621 1 Handle
-26 12G2472 1 Polyester Film
-27 12G2473 1 Pressure Spring
-28 12G2474 1 Lock Lever
-29 12G2475 1 Roll, Paper Pickup
-30 12G2476 1 Weight
-31 12G2477 1 Washer
-32 12G2337 2 Wave Washer
-33 12G2478 1 Washer
