Lexmark Optra W810 - Cooling Fan Motor (M3) and I;C Filter Removal

4-26 Service Manual
4023-001
Cooling Fan Motor (M3) and I/C Filter Removal
1. Remove the image transfer unit. (See “Image Transfer Unit
Removal” on page 4-22.)
2. Remove the filter (1).
3. Remove the filter fixing plate (2). (2 screws)
4. Remove the cooling fan motor M3 (1). (1 connector)
