Lexmark Optra W810 - Assembly 28: Finisher Paper Transport (B)

Parts Catalog 7-83
4023-001
Assembly 28: Finisher Paper Transport (B)
Ref
Part
Number
Units Description
28-1 12G3124 2 Polyester Film
-2 12G3125 1 Guide
-3 12G2911 1 Shoulder Screw
-4 12G3126 2 Sponge
-5 12G3127 1 Guide
-6 12G3128 1 Guide
-7 12G2971 4 Bushing
-8 12G3129 4 Ball Bearing
-9 12G3130 1 Pulley 32t
-10 12G3131 1 Flange
-11 12G3132 1 Timing Belt
-12 12G3133 1 Bracket
-13 12G3134 1 Motor, M2 Transport, Upper Exit
-14 12G3135 2 Shoulder Screw
-15 12G3136 2 Shoulder Screw
-16 12G3137 1 Guide
-17 12G3138 1 Actuator
-18 12G3139 1 Torsion Spring
-19 12G3140 2 Plate Spring
-20 12G3038 4 Cushion
-21 12G3141 1 Torsion Spring
-22 12G3142 1 Harness
-23 12G3143 1 Bracket
-24 12G2999 1 Photo Interrupter, PC3 Finish Tray
-25 12G3144 1 Roller
-26 12G3145 2 Shaft
-27 12G2924 4 Roll
-28 12G3146 1 Torsion Spring
-29 12G3147 1 Guide Plate
-30 12G3148 1 Cover
-31 12G3149 1 Label
-32 12G3150 1 Polyester Film
-33 12G3151 10 Shaft
