Repair Information 4-91
4023-001
Mailbox Removal Procedures
Storage Unit Cover Removals
Note: Removing the rear cover lets you access the main board and
transport motor. Removing the front cover lets you access each
solenoid.
Rear Cover (1) Removal
Remove 6 screws.
Front Cover (2) Removal
Remove 6 screws.
Top Cover (3) Removal
1. Remove rear cover (1).
2. Remove front cover (2).
3. Remove top cover (3).
To Next Page
