Lexmark Optra W810 - Assembly 22: Paper Deck Drive

Parts Catalog 7-67
4023-001
Assembly 22: Paper Deck Drive
Ref
Part
Number
Units Description
22-1 12G2745 1 Harness
-2 12G2746 1 IC
-3 12G2747 1 Harness
-4 12G2748 1 PWB-A, Drive Board
Note: Remove IC (reference 2) from old board
and place on new board.
-5 12G2749 1 Motor, HMOT Paper Transport
-6 12G2750 2 Lever
-7 12G2680 1 Photo Interrupter, RS1, RS2 Front
-8 12G2751 3 PWB Support
-9 12G2752 2 Bracket
-10 12G2753 1 Harness
-11 12G2754 1 Harness
-12 12G2755 1 Harness
-13 12G2756 2 Pressure Spring
-14 12G2757 2 Shaft
-15 12G2758 2 Gear 16/32 T
-16 12G2759 1 Gear 16/32 T
-17 12G2806 4 Bush
-18 12G2760 2 Gear 58 T
-19 12G2761 1 Axle Plate
-20 12G2679 4 Bushing
-21 12G2762 1 Gear 72 T
-22 12G2763 1 Gear 72 T
-23 12G2764 2 Shaft
-24 12G2765 1 Worm Gear
-25 12G2766 1 Gear 16/32 T
-26 12G2767 1 Worm Gear
-27 12G2768 1 Motor, EMOT Paper Lift
-28 12G2769 2 Holder
-29 12G2770 1 Pulley 18 T
-30 12G2771 1 Timing Belt
-31 12G2772 1 Ply Gear 16/50 T
