Parts Catalog 7-131
4023-001
Assembly 43: Mailbox Drive
Ref
Part
Number
Units Description
43-1 12G2940 1 Photo Interrupter, PC1 Non-sort
-2 12G2844 2 Ball Bearing
-3 12G2941 1 Pulley 64 T
-4 12G2942 1 Timing Belt
-5 12G2943 1 Pulley
-6 12G2944 1 Pulley 16 T
-7 12G2945 1 Timing Belt
-8 12G2946 1 Ply Gear 64/18 T
-9 12G2947 1 Harness
-10 12G2948 1 Holder
-11 12G2949 1 Cord Bushing
-12 12G2950 1 Harness
-13 12G2951 1 Cord Bushing
-14 12G2952 1 Harness
-15 12G2953 1 Harness
-16 12G2954 1 Fuse 0.5A
-17 12G2955 1 PWB-A, Main Drive Board
-18 12G2956 2 PWB Support 9.53h
-19 12G2957 4 PWB Support 9.53h
-20 12G2958 1 Bracket
-21 12G2959 1 Microswitch, Power S1
-22 12G2960 1 Holder
-23 12G2961 1 Bracket
-24 12G2872 1 Ground Plate
-25 12G2873 1 Magnet Catch
-26 12G2962 1 Motor Asm, Transport M1
-27 12G2963 1 Bracket
-28 12G2964 1 Shaft
-29 12G2173 1 Stopper
-A 1 Parts Packet 1, PN 12G3400
-C 1 Parts Packet 3, PN 12G3402
-G 1 Parts Packet 7, PN 12G3406
-J 1 Parts Packet 10, PN 12G3409
