Lexmark Optra W810 - Assembly 20: Paper Deck Paper Take-Up (A)

Parts Catalog 7-59
4023-001
Assembly 20: Paper Deck Paper Take-up (A)
Ref
Part
Number
Units Description
20-1 12G2666 1 Guide Plate
-2 12G2667 3 Photo Interrupter, PPSO-2
-3 12G2664 5 Shoulder Screw
-4 12G2668 1 Reinforce Plate
-5 12G2669 1 Bracket
-6 12G2670 2 Polyester Film
-7 12G2671 2 Holder
-8 12G2672 2 Photo Interrupter, RSEN, S1
-9 12G2673 1 Arm
-10 12G2674 1 Tension Spring
-11 12G2675 1 Arm
-12 12G2676 2 Stopper
-13 12G2677 2 Bracket
-14 12G2678 1 Ground Plate
-15 12G2679 4 Bushing
-16 12G2680 2 Photo Interrupter, LS1,LS2
-17 12G2681 2 Tension Spring
-18 12G2682 2 Shaft
-19 12G2683 2 Stopper Ring
-20 12G2684 2 Shaft
-21 12G2685 2 Arm
-22 12G2686 2 Gear 26 T
-23 12G2687 2 Shaft
-24 12G2688 2 Pulley 20 T
-25 12G2689 2 Tension Spring
-26 12G2690 1 Timing Belt
-27 12G2691 2 Clutch, P1CL, P2CL
-28 12G2692 1 Pulley 18 T
-29 12G2693 2 Arm
-30 12G2694 2 Roller, Paper Transport
-31 12G2695 1 Harness
-32 12G2696 1 Harness
-33 12G2697 1 Harness
