Parts Catalog 7-31
4023-001
Assembly 11: Printer Drive
Ref
Part
Number
Units Description
11-1 12G2404 1 Guide
-2 12G2405 1 Torsion Spring
-3 12G2406 1 Bracket
-4 12G2407 1 Micro Switch, S2 Right Side Door
-5 12G2408 1 Motor, M2 Transport Drive
-6 12G2409 1 Holder
-7 12G2410 1 PWB-I, Paper Size Board
-8 12G2411 1 CPM Switch Board, PWB-L
-9 12G2412 1 Bracket
-10 12G2413 1 Fan Motor, M4 Power Unit Cooling
-11 12G2414 1 Lever
-12 12G2415 1 Motor, M1 Image/PC Cartridge
-13 12G2416 1 Bracket
-14 12G2417 1 Cover
-15 12G2418 1 Harness
-16 12G2419 1 Bracket
-17 12G2042 2 Holder
-18 12G2420 1 Bracket
-19 12G2421 1 Ferrite Core
-20 12G2422 1 Harness
-21 12G2423 2 Bushing
-22 12G2424 1 Bracket
-23 12G2425 1 Harness
-24 12G2426 2 Pin
-25 12G2427 2 Gear 34t
-26 12G2428 1 Lever
-27 12G2429 1 Bracket
-28 12G2430 1 Clutch, CL2 Transport
-29 12G2431 1 Cover
-30 12G2081 1 Photo Interrupter, PC5 Near Empty
-31 12G2432 1 Harness
-32 12G2433 1 Drive Unit
-33 12G2434 1 Label
To Next Page
