Parts Catalog 7-39
4023-001
Assembly 13: 500 Sheet Unit Housing
Ref
Part
Number
Units Description
13-1 12G2528 1 Guide
-2 12G2529 2 Bracket
-3 12G2530 2 Plate Spring
-4 12G2531 1 Rubber Foot
-5 12G2532 1 Frame
-6 12G2533 1 Cover
-7 12G2534 1 Ground Plate
-8 12G2535 1 Bracket
-9 12G2536 1 Harness
-10 12G2537 1 Bracket
-11 12G2538 1 PWB-A, Main Controller Board
-12 12G2539 1 PWB Support 6.35h
-13 12G2540 1 Harness
-14 12G2541 1 Bracket
-15 12G2542 4 Shoulder Screw
-16 12G2543 1 Rubber Foot
-17 12G2544 1 Holder
-18 12G2545 1 Spring
-19 12G2546 1 Bracket
-20 12G2547 1 Bracket
-21 12G2548 2 Pressure Spring
-22 12G2549 2 Shoulder Screw
-23 12G2550 2 Shoulder Screw
-24 12G2551 1 Bracket
-25 12G2552 2 Rubber Foot
-26 12G2553 1 Bracket
-27 12G2554 1 Bracket
-28 12G2555 1 Rail
-29 12G2556 1 Pressure Spring
-30 12G2557 1 Bracket
-31 12G2042 4 Holder
To Next Page
