2-32 Service Manual
4023-001
LCC 2500-Sheet Tray 4 Symptom Table
Mailbox Symptom Table
Symptom Action
No Power Check printer power. Check
connectors. Check LCC main board
PWB-A and replace if necessary.
Replace printer main engine board
PWB-A if necessary.
No Paper Feed Go to
“Paper Feed LCC (2500-
Sheet Tray 4) Service Check” on
page 2-51
.
No Pickup from Tray 4 Go to
“Paper Feed LCC (2500-
Sheet Tray 4) Service Check” on
page 2-51
.
Paper Feed Problems Go to
“Paper Feed LCC (2500-
Sheet Tray 4) Service Check” on
page 2-51
.
Paper Lift and Other Problems Go to
“Paper Deck 2500-Sheet
(LCC) Option” on page 1-45
.
Symptom Action
No Power Go to
“Mailbox Power Service
Check” on page 2-58
.
Transport Drive Problems Go to
“Mailbox Transport Drive
Service Check (935)” on
page 2-59.
Bin Switching Problems Go to
“Mailbox Bin 1–10 Service
Check” on page 2-59.
Other Problems Go to
“Mailbox/Transport Option”
on page 1-61
.
