Lexmark Optra W810 - Assembly 16: 500 Sheet Unit Paper Tray Unit (B)

Parts Catalog 7-49
4023-001
Assembly 16: 500 Sheet Unit Paper Tray Unit (B)
Ref
Part
Number
Units Description
16-1 12G2622 2 Screw
-2 12G2623 6 Screw
-3 12G2624 1 Label
-4 12G2625 1 Label
-5 12G2626 1 Label
-6 12G2627 1 Plate Spring
-7 12G3372 1 Plate Spring
-8 12G2629 1 Friction Sheet
-9 12G2630 1 Stopper
-10 12G2631 1 Reinforce Plate
-11 12G2632 1 Plate Spring
-12 12G2633 2 Sheet
-13 12G2634 1 Regulating Plate
-14 12G2635 1 Terminal
-15 12G2410 2 PWB-I, Paper Size Board
-16 12G2636 2 Holder
-17 12G2637 1 Terminal
-18 12G2638 1 Cover
-19 12G2639 1 Harness
-20 12G2640 1 Reinforce Plate
-21 12G2641 1 Plate
-22 12G2642 1 Tension Spring
-23 12G2643 1 Lever
-24 12G2486 1 Wiring Saddle 5.2h
-25 12G2487 2 Wiring Saddle 6.4h
-26 12G2490 9 Edge Cover 8.5h
-27 12G2491 1 Edge Cover 15.4h
-D 1 Parts Packet 4, PN 12G3403
