Parts Catalog 7-13
4023-001
Assembly 4: Printer Hopper
Ref
Part
Number
Units Description
4-1 12G2105 1 Cushion
-2 12G2106 1 Cover
-3 12G2107 1 Guide
-4 12G2108 1 Detecting Plate
-5 12G2109 1 Magnet
-6 12G2110 1 Scraper Plate
-7 12G2111 2 Bushing
-8 12G2112 1 Gear 29t
-9 12G2113 1 Gear 37t
-10 12G2114 1 Lever
-11 12G2115 1 Gear 26t
-12 12G2116 1 Duct
-13 12G2089 1 Fan Motor, M8 Ozone
-14 12G2117 1 Cover
-15 12G3425 1 Transfer Ozone BM (includes ozone filter and
transfer unit)
-16 12G2119 1 Screw
-17 12G2120 1 Set Plate
-18 12G2121 1 Gear 39t
-19 12G2122 1 Gear 45t
-20 12G2123 1 Housing
-21 12G2124 2 Bushing
-22 12G2125 2 Gear 20t
-23 12G2126 2 Shaft
-24 12G2127 2 Worm Gear
-25 12G2128 1 Bracket
-26 12G2129 1 PWB-Motor, M7(sub-hopper), M6(main hopper)
-27 12G2130 2 Gear 24t
-28 12G2131 1 Bushing
-29 12G2132 1 Gear 30t
-30 12G2133 1 Holder
-31 12G2134 1 Shoulder Screw
-32 12G2135 1 Spiral Roller
