Lexmark Optra W810 - Edge Guide and Trailing Edge Stop; Paper Lifting Plate

1-20 Service Manual
4023-001
Edge Guide and Trailing Edge Stop
Universal Cassette/500-Sheet Tray 2 & 3
The edge guide and trailing edge stop of the universal cassette slide
to accommodate different paper sizes.The edge guide and trailing
edge stop of the fixed paper size cassette are attached in fixed
positions.
Fixed Paper Size Cassette
Paper Lifting Plate
Two paper lifting springs in each cassette constantly raise the paper
lifting plate.
