Lexmark Optra W810 - Assembly 32: Finisher Punch Unit

Parts Catalog 7-101
4023-001
Assembly 32: Finisher Punch Unit
Ref
Part
Number
Units Description
32-1 12G3288 1 Mounting Plate
-2 12G3289 2 Shoulder Screw
-3 12G3290 2 Bushing
-4 12G3291 1 Bracket
-5 12G3292 1 Bushing
-6 12G3293 1 Gear 21t
-7 12G3294 1 Gear 14/31t
-8 12G3295 1 Gear 20t
-9 12G3296 1 Gear 20t
-10 12G3297 1 Bracket
-11 12G3298 1 Bracket
-12 12G3299 1 PWB-motor, M1 Transport
-13 12G3300 1 Bracket
-14 12G3301 1 Gear 22/38t
-15 12G3302 1 Label Jam Removal
-16 12G3303 1 Label Jam Removal
-17 12G3304 1 Guide Plate
-18 12G3305 1 Bracket
-19 12G3306 1 Shaft
-20 12G3307 1 Pressure Spring
-21 12G3309 1 Punch Unit (3-hole)
-21 12G3310 1 Punch Unit (4-hole)
-22 12G3311 2 Knob
-23 12G3312 2 Shoulder Screw
-A 1 Parts Packet 1, PN 12G3400
-B 1 Parts Packet 2, PN 12G3401
-C 1 Parts Packet 3, PN 12G3402
-E 1 Parts Packet 5, PN 12G3404
-F 1 Parts Packet 6, PN 12G3405
-G 1 Parts Packet 7, PN 12G3406
