Parts Catalog 7-93
4023-001
Assembly 30: Finisher Assistance Tray
Ref
Part
Number
Units Description
30-1 12G3069 1 Microswitch, S7 1st Tray Door
-2 12G3223 1 Bracket
-3 12G3224 1 Motor, Paper Holding Tray M10
-4 12G3225 2 Bracket
-5 12G3106 2 Photo Interrupter, PC9, PC10
-6 12G3226 1 Flange
-7 12G3227 1 Pulley 28t
-8 12G2971 2 Bushing
-9 12G3228 1 Frame
-10 12G3229 1 Frame
-11 12G3230 1 Shaft
-12 12G3231 2 Pulley 19t
-13 12G3232 2 Holder
-14 12G3233 1 Bracket
-15 12G3234 4 Sub Tray
-16 12G3235 2 Plate Nut
-17 12G3236 18 Cushion
-18 12G3237 16 Slider
-19 12G3238 1 Reinforce Plate
-20 12G3239 2 Bracket
-21 12G3240 2 Pulley 19t
-22 12G3161 2 Flange
-23 12G3241 1 Rail
-24 12G3242 1 Frame
-25 12G3243 1 Plate
-26 12G3244 1 Rail
-27 12G3245 1 Support
-28 12G3246 1 Sheet
-29 12G2102 2 Stopper
-30 12G3247 1 Timing Belt
-31 12G3248 2 Timing Belt
