Lexmark Optra W810 - Assembly 29: Finisher Paper Aligning

Parts Catalog 7-87
4023-001
Assembly 29: Finisher Paper Aligning
Ref
Part
Number
Units Description
29-1 12G3168 1 PWB-Motor, Staple Paddle M6
-2 12G3169 1 Shaft
-3 12G3170 1 Bracket
-4 12G3171 2 Gear 41t
-5 12G3172 1 Gear 25/26t
-6 12G3157 1 Gear 24t
-7 12G3173 1 Gear 18/27t
-8 12G3174 1 Arm
-9 12G3175 1 Arm
-10 12G3176 2 Clutch Spring
-11 12G3177 1 Photo Switch, Top Position PC12
-12 12G3178 1 Tension Spring
-13 12G3179 1 Holder
-14 12G3180 1 Bracket
-15 12G3181 1 Arm
-16 12G3182 1 Torsion Spring
-17 12G3183 3 Gear 19t
-18 12G3184 1 Paddle
-19 12G3185 1 Actuator
-20 12G3186 1 Actuator
-21 12G3106 4 Photo Interrupter, PC4–PC7
-22 12G3187 1 Guide
-23 12G2102 4 Stopper
-24 12G3188 2 Bracket
-25 12G3189 1 Timing Belt
-26 12G3190 1 Motor, Shift M5
-27 12G3191 2 Flange
-28 12G3192 2 Pulley 22t
-29 12G3193 2 Pressure Spring
-30 12G2844 2 Ball Bearing
-31 12G3507 2 Roll
-32 12G3194 2 Slider
-33 12G3195 1 Stopper
