Lexmark Optra W810 - Finisher Stapler Drive Service Check (997); Finisher Paper Holding Tray Drive Service Check (998)

2-56 Service Manual
4023-001
Finisher Stapler Drive Service Check (997)
Finisher Paper Holding Tray Drive Service Check (998)
FRU Action
1Gears
Rubber Paddle
Paddle Motor
(M6)
Finisher Main
Board PWB-A
Ensure all connectors are plugged in. If the paddle
motor does not turn during POR, check for binds
and gear damage. Ensure the rubber paddle is not
damaged. If the paddle motor still does not turn
during POR, replace it. If problem persists, replace
finisher main board PWB-A.
2 Stapler Unit If the stapler does not energize, check for jammed
staples or binds. Replace parts as necessary.
Replace staple unit.
FRU Action
1 Paper Hold
Tray Home
Sensor (PC9)
Check the paper holding tray home sensor
operation. Replace if necessary.
2 Paper Holding
Tray Belt
Guides
Ensure the trays, drive belt and guides are not
damaged. Replace if necessary.
3 Paper Holding
Motor (M10)
Ensure all connectors are plugged in. Replace the
motor if it does not turn when the printer is turned
on and POR is started.
4 Finisher Main
Board PWB-A
If problem persists, replace the finisher main board
PWB-A.
