Lexmark Optra W810 - Assembly 33: Finisher Stapler Unit;Finisher Tray

Parts Catalog 7-103
4023-001
Assembly 33: Finisher Stapler Unit/Finisher Tray
Ref
Part
Number
Units Description
33-1 12G3313 2 Guide
-2 12G3314 1 Plate Spring
-3 12G3315 2 Shoulder Screw
-4 12G3316 2 Pressure Spring
-5 12G3313 2 Pressure Spring
-6 12G3317 1 Harness
-7 12G3318 1 Bracket
-8 12G3319 1 Handle
-9 12G3320 1 Label Jam Removal
-10 12G3321 1 Cover
-11 12G3322 1 Polyester Film
-12 12G3323 1 Plate
-13 12G3324 1 Stapler Unit
-14 12G3325 1 Bracket
-15 12G3326 1 Harness
-16 12G3327 1 Guide
-17 12G3328 2 Bushing
-18 12G3329 3 Holder
-19 12G3330 3 Belt
-20 12G3331 3 Pulley
-21 12G3332 3 Pulley
-22 12G3333 3 Holder
-23 12G3334 1 Pulley 18t
-24 12G3335 1 Bracket
-25 12G3336 1 Motor, Finisher Tray M8
-26 12G3337 1 Timing Belt
-27 12G3226 1 Flange
-28 12G3338 1 Pulley 40t
-29 12G2971 2 Bushing
-30 12G3339 2 Gear 18t
-31 12G3340 1 Pulley
-32 12G3341 1 Shaft
-33 12G3342 1 Shaft
