2-30 Service Manual
4023-001
Paper Jam in Synchronizing Roll Go to “Paper Feed Synchronizing
Roll/Registration Service Check”
on page 2-45
.
Paper Jam in Fuser/Exit Go to
“Paper Feed Fuser/Exit
Service Check” on page 2-46
.
Paper Jam in Horizontal
Transport
Go to
“Paper Feed In Horizontal
Transport Service Check” on
page 2-48
.
Paper Jam in Mailbox Go to
“Paper Feed Mailbox
Service Check” on page 2-48
.
Paper Jam in Finisher Go to
“Paper Feed Finisher
Service Check” on page 2-50
.
Paper Jam in LCC (2500-Sheet) Go to
“Paper Feed LCC (2500-
Sheet Tray 4) Service Check” on
page 2-51.
Paper Jam or Malfunction of Hole
Punch
Go to
“Paper Feed Hole Punch
Service Check” on page 2-52.
Symptom Action
