Lexmark Optra W810 - Assembly 15: 500 Sheet Unit Paper Tray Unit (A)

Parts Catalog 7-47
4023-001
Assembly 15: 500 Sheet Unit Paper Tray Unit (A)
Ref
Part
Number
Units Description
15-1 12G2597 2 Cork
-2 12G2598 1 Shaft
-3 12G3371 4 Washer
-4 12G2600 4 Screw
-5 12G2601 1 Label Max Level
-6 12G3509 4 Collar
-7 12G2603 2 Hold Plate
-8 12G2604 1 Label Paper Size
-9 12G2605 1 Guide Plate
-10 12G2606 1 Regulating Plate
-11 12G2607 1 Lifting Plate
-12 12G2608 1 Lifting Plate
-13 12G2609 1 Pressure Spring
-14 12G2610 1 Cassette Body
-15 12G2611 1 Label Cassette
-16 12G2612 2 Pressure Spring
-17 12G2613 1 Gear 14t
-18 12G2614 1 Shoulder Screw
-19 12G2615 1 Regulating Plate
-20 12G2616 1 Knob
-21 12G2617 1 Pressure Spring
-22 12G2618 1 Lever
-23 12G2619 1 Shaft
-24 12G2620 1 Guide Plate
-25 12G2621 1 Handle
-G 1 Parts Packet 7, PN 12G3406
