Lexmark Optra W810 - Assembly 42: Mailbox Paper Transport (E)

Parts Catalog 7-129
4023-001
Assembly 42: Mailbox Paper Transport (E)
Ref
Part
Number
Units Description
42-1 12G2927 3 Guide
-2 12G2922 2 Guide
-3 12G2920 5 Gear 17t
-4 12G2891 4 Gear 17t
-5 12G2928 8 Gear 19t
-6 12G2924 20 Roll
-7 12G2929 12 Holder
-8 12G2930 12 Plate Spring
-9 12G2911 5 Shoulder Screw
-10 12G2923 10 Shaft
-11 12G2892 5 Ball Bearing
-12 12G2931 12 Roll
-13 12G2932 10 Plate Spring
-14 12G2893 5 Roller
-15 12G2971 5 Bushing
-16 12G2933 1 Bushing
-17 12G2934 1 Solenoid, Deflect SL3
-18 12G2901 4 Holder
-19 12G2935 4 Tension Spring
-20 12G2899 4 Stopper
-21 12G2896 4 Bushing
-22 12G2926 2 Guide
-23 12G2936 3 Guide
-24 12G2937 6 Plate Spring
-C 1 Parts Packet 3, PN 12G3402
-D 1 Parts Packet 4, PN 12G3403
-G 1 Parts Packet 7, PN 12G3406
-J 1 Parts Packet 10, PN 12G3409
