Parts Catalog 7-9
4023-001
Assembly 3: Printer Frames (B)
Ref
Part
Number
Units Description
3-1 12G2073 1 Duct
-2 12G2074 1 Wire, Paper Feed Door
-3 12G2075 1 Guide
-4 12G2076 1 Frame
-5 12G2077 1 Flange, Paper Feed Door
-6 12G2078 1 Shaft
-7 12G2079 1 Pressure Spring, PF Door
-8 12G2080 1 Flange, PF Door
-9 12G2081 1 Photo Interrupter, PC12 Exit Full
-10 12G2082 1 Tension Spring, PF Door
-11 12G2083 1 Holder
-12 12G2084 1 Shutter
-13 12G2085 1 Torsion Spring
-14 12G2324 1 PW Board-R, PWB-R2, Resistor Board
-15 12G2086 1 Ground Plate
-16 12G2087 1 Ground Plate
-17 12G2088 1 Bracket
-18 12G2089 1 Fan Motor, M9 Image/PC Cartridge
-19 12G2090 1 Duct
-20 12G2091 2 Seal
-21 12G2092 1 Duct
-22 12G2093 1 Seal
-23 12G2094 1 Holder
-24 12G2095 1 Seal
-25 12G2096 1 Lamp, Erase (LA1)
-26 12G2097 2 Plate Spring
-27 12G2098 1 Seal
-28 12G2099 1 Bracket
-29 12G2100 1 Tension Spring
-30 12G2101 1 Bracket
-31 12G2102 1 Stopper
