Lexmark Optra W810 - Paper Feed Finisher Service Check

2-50 Service Manual
4023-001
Paper Feed Finisher Service Check
FRU Action
1 Transport
Motor (M1)
Check for motor and gear damage. Replace as
necessary.
2 Entrance Roll Check entrance roll for wear or damage. Replace if
necessary.
3 • Transport
Roller
• Transport
Roll
Check transport roller and roll for wear or damage.
Replace if necessary.
4•Upper
Entrance
Switching
Plate
•Lower
Entrance
Switching
Plate
• Upper Exit
Motor (M2)
Check upper entrance switching plate, lower
entrance switching plate, upper exit motor (M2) for
wear or damage. Replace if necessary.
5•1st Tray Exit
Roller
•1st Tray Exit
Roll
• Finisher
Tray Exit
Roller
• Finisher
Tray Exit
Roll
Check rollers and rolls for wear or damage.
Replace if necessary.
