Parts Catalog 7-5
4023-001
Assembly 2: Printer Frames (A)
Ref
Part
Number
Units Description
2-1 12G2031 1 Holder Asm
-2 12G2032 2 Label High Voltage
-3 12G2033 3 Pressure Spring
-4 12G2034 1 Holder Asm
-5 12G2035 1 Harness
-7 12G2037 2 Rubber Foot
-8 12G2038 1 Plate Spring
-9 12G2039 1 Base Frame
-10 12G2040 1 Frame
-11 12G2041 1 Rubber Foot
-12 12G2042 4 Holder
-13 12G2043 1 Collar
-14 12G2044 1 Bracket
-15 12G2045 1 Harness
-16 12G2046 1 Switch, Power, S1 Main SW
-17 12G2047 1 Harness
-18 12G2048 1 Bracket
-19 12G2049 1 Switch, SW# Interlock S3 Right Side Door
-20 12G2050 1 Guide Plate
-21 12G2051 1 Harness
-22 12G2052 1 Lever
-23 12G2053 3 Retaining Ring
-24 12G2054 1 Tension Spring
-25 12G2055 1 Bracket
-26 12G2056 3 Shaft
-27 12G2057 1 Joint
-28 12G2058 1 Lever
-29 12G2059 1 Guide
-30 12G2060 1 Harness
-31 12G2061 1 Tension Spring
-32 12G2062 1 Lever
-33 12G2063 1 Plate Spring
To Next Page
