Lexmark Optra W810 - Paper Feed Hole Punch Service Check

2-52 Service Manual
4023-001
Paper Feed Hole Punch Service Check
FRU Action
Note: With paper entering the finisher from the horizontal transport roller,
check the following for hole punch paper feed.
1 • Transport
Motor M1
• Entrance
Roller
Check gear at finisher transport motor M1. Check
entrance roller for wear or damage. Replace as
necessary.
2 Upper Exit
Motor
Ensure that the upper exit motor pulls paper into
the punch assembly and stops while transport roll
continues to turn. Replace parts as necessary.
3 Hole Punch
Assembly
Ensure that the electromagnetic clutch in the hole
punch assembly moves the punch rods to cut
holes. Ensure the hole punch box is empty and
push any tamped punch holes out of punch.
Replace the hole punch assembly if damaged.
4 Transport
Roller
Ensure that the upper exit motor turns the belt that
rotates the transport roller. Check the belt and roller
for damage. Replace as necessary.
