Parts Catalog 7-29
4023-001
Assembly 10: Printer Paper Take-up
Ref
Part
Number
Units Description
10-1 12G2377 1 Polyester Film
-2 12G2378 1 Guide Bar
-3 12G2379 1 Rail
-4 12G2380 1 Ground Plate
-5 12G2381 1 Harness
-6 12G2382 1 Holder
-7 12G2383 1 PWB-H Humidity Board
-8 12G2384 1 Bracket
-9 12G2385 2 Shoulder Screw
-10 12G2386 1 Bracket
-11 12G2387 1 Harness
-12 12G2388 1 Harness
-13 12G2389 1 PWB-HV1, High Voltage Power Supply
-14 12G2390 1 Actuator
-15 12G2081 1 Photo Interrupter, PC4 Empty
-16 12G2391 1 Cover
-17 12G2392 2 Cover
-18 12G2393 1 Shoulder Screw
-19 12G2394 1 Rail
-20 12G2395 1 Cover
-21 12G2042 1 Holder
-22 12G2041 1 Rubber Foot
-23 12G2396 1 Lever
-24 12G2397 1 Cover
-25 12G2398 1 Bracket
-26 12G2399 1 Terminal
-27 12G2400 1 Harness
-28 12G2401 1 Pad
-29 12G2402 1 Ground Plate
-B 1 Parts Packet 2, PN 12G3401
-D 1 Parts Packet 4, PN 12G3403
-E 1 Parts Packet 5, PN 12G3404
To Next Page
