Parts Catalog 7-19
4023-001
Assembly 6: Printer Fuser (B)
Ref
Part
Number
Units Description
6-1 12G2238 1 PW Board-R1, Fuser Frame Resistor Board
-2 12G2242 1 Thermistor, TH2
-3 12G2255 1 Thermostat, TS1
-4 12G2256 1 Thermal Fuse, TF1
-5 12G2262 1 Heater, 110V
-5 12G2263 1 Heater, 220V
-A 1 Parts Packet 1, PN 12G3400
-B 1 Parts Packet 2, PN 12G3401
-C 1 Parts Packet 3 PN 12G3402
-D 1 Parts Packet 4, PN 12G3403
-G 1 Parts Packet 7, PN 12G3406
-I 1 Parts Packet 9, PN 12G3408
Note: Illustrated parts that do not have a callout are for reference only.
