Diagnostic Information 2-51
4023-001
Paper Feed LCC (2500-Sheet Tray 4) Service Check
FRU Action
Note: With lift 1 paper present.
1•Paper Take-
Up Clutch 1
(P1CL)
• Paper Take-
Up Roll 1
• LCC Trans-
port Motor
(HMOT)
Ensure paper take-up clutch 1 turns on when paper
is in lift 1. Replace if necessary. Ensure paper take-
up roll 1 is not worn or damaged. Replace if neces-
sary. Replace the transport motor (HMOT) if neces-
sary.
Note: With lift 2 paper present, lift 1 empty.
1•Paper Take-
Up Clutch 2
(P2CL)
• Paper Take-
Up Roll 2
• LCC Trans-
port Motor
Ensure paper take-up clutch 2 turns on when paper
is in lift 2. Replace if necessary. Ensure paper take-
up roll 2 is not worn or damaged. Replace if neces-
sary. Replace the transport motor (HMOT) if neces-
sary.
2 • Paper Feed
Roll
Ensure the paper feed roll is not worn or damaged.
Replace as necessary.
3•Separation
Clutch
(BCL)
• Separator
Roll
Ensure the clutch (BCL) turns on and the separator
roll is not worn or damaged. Replace as necessary.
4•Vertical
Transport
Roll
Ensure the vertical transport roll is not worn or
damaged. Replace if necessary.
To Next Page
