Parts Catalog 7-25
4023-001
Assembly 8: Printer Transport
Ref
Part
Number
Units Description
8-1 12G2321 1 Terminal
-2 12G2322 1 Bracket
-3 12G2323 1 Holder Asm
-4 12G2324 1 PWB-R Resistor Board
-5 12G2325 2 Pressure Spring
-6 12G2326 2 Plate Spring
-7 12G2327 2 Bushing
-8 12G2328 2 Tension Spring
-9 12G2329 4 Bushing
-10 12G2330 1 Clutch, CL1 Transport
-11 12G2331 1 Harness
-12 12G2332 1 Thermistor, TH1 Image/PC Cartridge
-13 12G3425 1 Transfer Ozone BM (includes transfer unit and
ozone filter)
-14 12G2334 1 Conveyor Roller
-15 12G2335 1 Conveyor Roller
-16 12G2336 1 Cleaning Pad Asm
-17 12G2337 2 Wave Washer
-18 12G2338 1 Washer
-19 12G2339 1 Actuator
-20 12G2340 1 Pressure Spring
-21 12G2341 1 Torsion Spring
-22 12G2081 1 Photo Interrupter, PC2 Timing
-23 12G2342 1 Ground Plate
-24 12G2343 1 Gear 13t
-25 12G2344 1 Gear 18t
-26 12G2345 1 Terminal
-27 12G2346 2 Ground Plate
-28 12G2347 1 Holder
-29 12G2348 1 Transport Unit
-D 1 Parts Packet 4, PN 12G3403
-E 1 Parts Packet 5, PN 12G3404
-G 1 Parts Packet 7, PN 12G3406
