Locations 5-27
4023-001
Symbol Name Symbol Name
M1 Transport Motor PC9 Paper Holding Tray Home
Position Sensor
M2 Upper Exit Motor PC10 Paper Holding Tray Retract
Position Sensor
M4 CD Aligning Motor PC11 Elevator Lower Limit Sensor
M5 Shift Motor PC12 Elevator Tray Retract
Position Sensor
M6 Paddle Motor PWB-A Control Board
M7 Paper Curl Taming Motor PWB-E 1st Tray Full Detecting
Sensor LED
M8 Finisher Tray Motor PWB-F Elevator Tray Empty Sensor
PQ
M9 Elevator Motor PWB-F 1st Tray Full Detecting
Sensor PQ
M10 Paper Holding Tray Motor S1 Upper Cover Set Switch
PC1 1st Tray Exit Sensor S2 Elevator Upper Limit
Interlock Switch 1
PC2 Finisher Tray Home Position
Sensor
S3 Elevator Upper Limit
Interlock Switch 2
PC3 Finisher Tray Exit Sensor S4 Staple Door Switch
PC4 1st Tray Empty Sensor S5 Elevator Lower Limit
Interlock Switch
PC5 CD Aligning Home Position
Sensor
S6 Set Switch
PC6 Shift Sensor S7 1st Tray Door Switch
PC7 Print Set Detecting Sensor SL1 Upper Entrance Switching
Solenoid
PC8 Elevator Tray Upper Surface
Sensor
To Next Page
