Parts Catalog 7-85
4023-001
Assembly 28 (cont.): Finisher Paper Transport (B)
Ref
Part
Number
Units Description
28-34 12G3152 5 Belt
-35 12G3153 1 Roller
-36 12G3154 1 Roller
-37 12G2896 2 Bushing
-38 12G3155 1 Roller
-39 12G3156 1 Gear 28t
-40 12G3157 1 Gear 24t
-41 12G3158 1 Ply Gear 19/28t
-42 12G3159 1 Pulley 15t
-43 12G3160 2 Pulley 19t
-44 12G3161 3 Flange
-45 12G3162 2 Arm
-46 12G3163 2 Tension Spring
-47 12G3164 1 Timing Belt
-48 12G3165 1 Solenoid, Transport SL1
-49 12G3166 1 Bracket
-50 12G3167 10 Roll
-B 1 Parts Packet 2, PN 12G3401
-C 1 Parts Packet 3, PN 12G3402
-F 1 Parts Packet 6, PN 12G3405
-G 1 Parts Packet 7, PN 12G3406
