Parts Catalog 7-89
4023-001
Assembly 29 (cont.): Finishing Paper Aligning
Ref
Part
Number
Units Description
29-34 12G3196 1 Spiral Roller
-35 12G3197 1 Frame
-36 12G2971 2 Bushing
-37 12G3198 1 Motor, Aligning M4
-38 12G3199 1 Cushion
-39 12G3200 1 Pulley 72t
-40 12G3201 1 Spiral Roller
-41 12G3202 1 Stopper
-42 12G3203 1 Timing Belt
-43 12G3204 1 Rail
-44 12G3205 1 Neutralizing Brush
-45 12G3065 1 PW Board-F, PWB-F
-46 12G3082 2 Collar
-47 12G3038 2 Cushion
-48 12G3206 1 PWB-Motor, Curl Control M7
-49 12G3207 1 Bracket
-50 12G3208 1 Shaft
-51 12G3209 3 Lever
-52 12G3210 1 Lever
-53 12G3211 4 Cushion
-54 12G3212 2 Arm
-55 12G3213 1 Holder
-56 12G3214 1 Shaft
-57 12G3215 1 Torsion Spring
-58 12G3216 1 Lever
-59 12G3217 1 Torsion Spring
-60 12G3218 1 Link
-61 12G3219 1 Rail
