Parts Catalog 7-105
4023-001
Assembly 33 (cont.): Finisher Stapler Unit/Finisher Tray
Ref
Part
Number
Units Description
33-34 12G3343 1 Shoulder Screw
-35 12G3344 1 Bracket
-36 12G3106 1 Photo Interrupter, PC2 Finish Pos.
-37 12G3345 1 Polyester Film
-38 12G3346 1 Lever
-39 12G3347 1 Roll
-40 12G3348 1 Tray
-41 12G3349 1 Stay
-42 12G3350 1 Tray
-43 12G3351 1 Torsion Spring
-44 12G3352 1 Torsion Spring
-45 12G3353 2 Rail
-46 12G3038 2 Cushion
-47 12G3354 2 Tension Spring
-48 12G3355 1 Guide
-49 12G2486 16 Wiring Saddle 5.2h
-50 12G2487 2 Wiring Saddle 6.4h
-51 12G3024 6 Wiring Saddle 16.8h
-52 12G3356 22 Wiring Saddle 14.4h
-53 12G2490 7 Edge Cover 8.5h
-54 12G2491 4 Edge Cover 15.4h
-54 12G2492 3 Edge Cover 25.0h
-55 12G3027 16 Wiring Saddle 3.8h
-56 12G3357 2 Cord Clamp
-57 12G2102 1 Stopper
-58 12G3358 1 Polyester Film
-59 12G3360 1 Polyester Film
-A 1 Parts Packet 1, PN 12G3400
-C 1 Parts Packet 3, PN 12G3402
-F 1 Parts Packet 6, PN 12G3405
-G 1 Parts Packet 7, PN 12G3406
