LSIS XGT Series User Manual

Chapter 9 NC Control Function
9-68
Parameters
Group
No.
Item
Description
1. Channel
parameters
10.
Workpiece
coordinate
system
1
Whether to use the
workpiece coordinate
system shift amount.
Set whether to use the workpiece coordinate
system shift amount.
0: Unused
1: Used
11
Workpiece coordinate
system shift amount 1
Set the workpiece coordinate system shift amount
for the X axis.
……
……
Set the workpiece coordinate system shift amount
for the 7 axes; Y, Z, A, B, C, U, V.
19
Workpiece coordinate
system shift amount 9
Set the workpiece coordinate system shift amount
for the W axis.
41
G54 workpiece coordinate
system value 1
Set the workpiece coordinate system value for the
X axis.
……
……
Set the G54 workpiece coordinate system values
for the 7 axes; Y, Z, A, B, C, U, V.
49
G54 workpiece coordinate
system value 9
Set the G54 workpiece coordinate system value
for the W axis.
51
G55 workpiece coordinate
system value 1
Set the G55workpiece coordinate system value for
the X axis.
……
……
Set the G55 workpiece coordinate system values
for the 7 axes; Y, Z, A, B, C, U, V.
59
G55 workpiece coordinate
system value 9
Set the G55 workpiece coordinate system values
for the W axis.
61
G56 workpiece coordinate
system value 1
Sets the G56 workpiece coordinate system values
for the X axis.
……
……
Set the G56 workpiece coordinate system values
for the 7 axes; Y, Z, A, B, C, U, V
69
G56 workpiece coordinate
system value 9
Set the G56 workpiece coordinate system values
for the W axis.
71
G57 workpiece coordinate
system value 1
Set the G57 workpiece coordinate system values
for the X axis.
……
……
Sets the G57 workpiece coordinate system values
for the 7 axes; Y, Z, A, B, C, U, V
