Section
Summary of Change
Internal Use
Only
8.17.1 Greasing Procedure, page
292
• Step 1, page 292
Added safety step:
• Shut down the engine, and remove the key from the ignition.
Tech Pubs
8.18 Checking and Adjusting
Endshields, page 299
• Step appeared before Step 4,
page 300
Removed the following redundant step:
• Close endshield.
Tech Pubs
9.1 Auto Header Height Control,
page 305
Added the following statement to the introduction:
• A lateral tilt two-sensor system is also available as an
optional kit.
Tech Pubs
9.1.2 Troubleshooting Auto
Header Height / Float Indicator,
page 306
Added topic. Tech Pubs
9.1.3 Sensor Output Voltage
Range – Combine Requirements,
page 307
• Table 9.1, page 307
Added “AGCO IDEAL
™
Series” to table.
ECN 58283
Manually Checking Voltage
Range – Two-Sensor System,
page 311
• Figure 9.10, page 311
Removed legend below picture. Tech Pubs
Adjusting Voltage Limits – Two-
Sensor System, page 316
• Step 1, page 316
Removed legend below picture. Tech Pubs
• Step
Added safety step:
• Shut down the engine, and remove the key from the ignition.
Tech Pubs
9.1.4 AGCO IDEAL
™
Series
Combines, page 318
Added AGCO IDEAL
™
Series topics. Tech Pubs
—
Removed topic titled “Replacing Float Indicator Cable.”
Product Support
9.1.6 Case IH 130 and 140 Series
Mid-Range Combines, page 333
Reworded topic title for simplicity. Tech Pubs
Calibrating Auto Header Height
Control – Case IH 5130/6130/
7130, 5140/6140/7140, page 338
Added WARNING:
• Clear the area of other persons, pets etc. Keep children away
from machinery. Walk around the machine to be sure no one
is under, on, or close to it.
Tech Pubs
9.1.7 Case IH 7010/8010, 120,
230, 240, and 250 Series
Combines, page 342
Added “250 Series” to the topic.
Tech Pubs
Checking Voltage Range from the
Combine Cab – Case IH 7010/
Added “250 Series” to the topic.
Tech Pubs
215184 xi Revision A
