MacDon D1 Series - Page 12

Section
Summary of Change
Internal Use
Only
8.10 Checking and Adjusting Skid
Shoe Settings, page 276
• Step 1, page 276 to Step 3,
page 276
• Step 6, page 276 to Step 8,
page 276
Added safety steps.
Tech Pubs
8.11.2 Adjusting Reel Clearance,
page 279
• Step 1, page 279
• Step 2, page 279
Added safety steps. Tech Pubs
8.11.2 Adjusting Reel Clearance,
page 279
• Step 5, page 280
Added NOTE. Tech Pubs
8.11.2 Adjusting Reel Clearance,
page 279
• Step 10, page 280
Added safety step.
Tech Pubs
8.13 Adjusting Draper Tension,
page 284
Changed the following WARNING to a DANGER:
• To avoid bodily injury or death from unexpected start-up or
fall of raised machine, always stop engine, remove key, and
engage safety props before going under machine for any
reason.
Tech Pubs
8.15 Checking and Adjusting
Draper Seal, page 287
Revised the IMPORTANT to clarify that the gap (deck seal) on new
drapers needs to be set to 1– 3 mm (1/16–1/8 in.). Removed
information about the break-in period because this does not
apply to an unloading and assembly manual.
Tech Pubs
8.15 Checking and Adjusting
Draper Seal, page 287
• Step 1, page 287
Revised associated picture to identify gap dimension.
Tech Pubs
8.15 Checking and Adjusting
Draper Seal, page 287
• Step 5, page 288
Added step. Tech Pubs
8.15 Checking and Adjusting
Draper Seal, page 287
• Step 6, page 288
Added information regarding header width and the quantity of
deck supports to the NOTE.
Product Support
8.15 Checking and Adjusting
Draper Seal, page 287
• Step 8, page 288
• Step 9, page 288
• Step 11, page 288
• Step 13, page 289
Added steps and associated pictures. Tech Pubs
215184 x Revision A
