MacDon D1 Series - Page 16

Section
Summary of Change
Internal Use
Only
• Step 6, page 471
10 Checking and Adjusting Reel
Height Sensor, page 487
Replaced the WARNING with the following DANGER:
• To avoid bodily injury or death from unexpected start-up or
fall of a raised machine, always stop engine and remove key
before leaving the operator’s seat, and always engage safety
props before going under the machine for any reason.
Tech Pubs
10 Checking and Adjusting Reel
Height Sensor, page 487
• Figure 10.1, page 487
Added AGCO IDEAL
™
to picture legend.
ECN 58283
10 Checking and Adjusting Reel
Height Sensor, page 487
• See NOTE below Figure 10.1,
page 487
Reworded the NOTE as follows:
• For configuration (A), pointer (D) points to the FRONT of the
header.
• For configuration (B), pointer (D) points to the REAR of the
header.
Tech Pubs
10 Checking and Adjusting Reel
Height Sensor, page 487
• Step 1, page 487
Added safety step:
• Shut down the engine, and remove the key from the ignition.
Tech Pubs
10 Checking and Adjusting Reel
Height Sensor, page 487
• Table 10.1, page 488
Added AGCO IDEAL
™
to table.
ECN 58283
10 Checking and Adjusting Reel
Height Sensor, page 487
• Step 10, page 489
Added safety step:
• Engage the reel safety props.
Tech Pubs
10 Checking and Adjusting Reel
Height Sensor, page 487
• Step 17, page 489
Added safety step:
• Disengage the reel safety props.
Tech Pubs
11 Running up Header, page 491
Removed the following redundant step:
• Lower plastic pan under float module and check for shipping
materials/debris that may have fallen under float module
draper.
Tech Pubs
215184 xiv Revision A
