Omron Q2V Series User Manual

Standards Compliance
5
5.3 UL Standards
SIEPCYEUOQ2V01A Q2V Technical Manual 173
Model Terminal
Recommended
Gauge
AWG, kcmil
Applicable Gauge
AWG, kcmil
Wire
Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
Size Shape
4004
R/L1, S/L2, T/L3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4005
R/L1, S/L2, T/L3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4007
R/L1, S/L2, T/L3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4009
R/L1, S/L2, T/L3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
U/T1, V/T2, W/T3 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
-, +1, +2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
B1, B2 14 14 - 12 8 M3
0.5 - 0.6
(4.4 - 5.3)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
4012
R/L1, S/L2, T/L3 12 14 - 10 10 M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 14 14 - 12 10 M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 10 12 - 8 10 M4
1.5 - 1.7
(13.5 - 15)
B1, B2 14 14 - 12 10 M4
1.5 - 1.7
(13.5 - 15)
10
*2
14 - 10
*2
- M4
1.2 - 1.5
(10.6 - 13.3)
