7.4 Faults
226 SIEPCYEUOQ2V01A Q2V Technical Manual
Code Name Causes Possible Solutions
EF3 External Fault (Terminal DI3)
MFDI terminal DI3 caused an external fault through
an external device.
1. Find the device that caused the external fault and remove the
cause.
2. Clear the external fault input in the MFDI.
The wiring is incorrect. Correctly connect the signal line to MFDI terminal DI3.
External Fault [H1-03 = 20 to 2B] is set to MFDI
terminal DI3, but the terminal is not in use.
Correctly set the MFDI.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
EF4 External Fault (Terminal DI4)
MFDI terminal DI4 caused an external fault through
an external device.
1. Find the device that caused the external fault and remove the
cause.
2. Clear the external fault input in the MFDI.
The wiring is incorrect. Correctly connect the signal line to MFDI terminal DI4.
External Fault [H1-04 = 20 to 2B] is set to MFDI
terminal DI4, but the terminal is not in use.
Correctly set the MFDI.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
EF5 External Fault (Terminal DI5)
MFDI terminal DI5 caused an external fault through
an external device.
1. Find the device that caused the external fault and remove the
cause.
2. Clear the external fault input in the MFDI.
The wiring is incorrect. Correctly connect the signal line to MFDI terminal DI5.
External Fault [H1-05 = 20 to 2B] is set to MFDI
terminal DI5, but the terminal is not in use.
Correctly set the MFDI.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
EF6 External Fault (Terminal DI6)
MFDI terminal DI6 caused an external fault through
an external device.
1. Find the device that caused the external fault and remove the
cause.
2. Clear the external fault input in the MFDI.
The wiring is incorrect. Correctly connect the signal line to MFDI terminal DI6.
External Fault [H1-06 = 20 to 2B] is set to MFDI
terminal DI6, but the terminal is not in use.
Correctly set the MFDI.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
EF7 External Fault (Terminal DI7)
MFDI terminal DI7 caused an external fault through
an external device.
1. Find the device that caused the external fault and remove the
cause.
2. Clear the external fault input in the MFDI.
The wiring is incorrect. Correctly connect the signal line to MFDI terminal DI7.
External Fault [H1-07 = 20 to 2B] is set to MFDI
terminal DI7, but the terminal is not in use.
Correctly set the MFDI.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
Err EEPROM Write Error
There was a problem with the EEPROM hardware. • Re-energize the drive.
• If the fault stays, replace the control board or the drive.
Contact the manufacturer or your nearest sales representative
to replace the board.
Electrical interference corrupted the data while it
was writing to the EEPROM of the drive.
• Push ENTER Key.
• Set the parameters again.
Note:
Do a Fault Reset to clear the fault.
Code Name Causes Possible Solutions
FbH Excessive PID Feedback
The FbH detection level is set incorrectly. Adjust b5-36 [PID HiHi Limit Level] and b5-37 [PID HiHi
Time].
There is a problem with the PID feedback wiring. Correct errors with the PID control wiring.
The feedback sensor is not operating correctly. Examine the sensors on the control device side.
