Specifications
10
10.5 Model Specifications (Three-Phase 400 V Class)
SIEPCYEUOQ2V01A Q2V Technical Manual 297
Model Duty Rating 4018 4023 4031 4038 4044 4060
Output
Rated Output
Capacity
*2
(kVA)
HD 11.3 13.7 18.3 23.6 29.7 34.3
ND 13.3 17.8 23.6 29 33.5 45.7
Rated Output
Current (A)
HD 14.8 18.0 24.0 31.0 39.0 45.0
ND 17.5 23.4 31.0 38.0 44.0 60
Overload Tolerance
• HD: 150% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
• ND: 110% of the rated output current for 60 seconds. The permitted frequency of overload is once every 10
minutes.
Note:
Derating may be necessary for applications that start and stop frequently.
Carrier Frequency
HD: 8 kHz without derating the drive capacity.
ND: 2 kHz without derating the drive capacity.
Derate the drive capacity to use values to 15 kHz maximum.
Maximum Output Voltage
Three-phase 380 V to 480 V
Note:
The maximum output voltage is proportional to the input voltage.
Maximum Output Frequency
• V/f Control, OLVector, PM OLVector: 590 Hz
• PM AOLVector: 270 Hz
• EZ Vector: 120 Hz
Measures for
Harmonics
DC reactor External options
Braking Device Braking Transistor Standard internal characteristics
EMC Filter
EMC Filter
IEC61800-3
Category C2 (Conducted emission)
Power Supply
Rated Voltage/Rated Frequency Three-phase AC power supply 380 V to 480 V at 50/60 Hz
Permitted Voltage Fluctuation -15% to +10%
Permitted Frequency Fluctuation ±5%
Input Power
(kVA)
HD
14 18 27 36 47 55
ND
18 22 35 40 55 74
*1 The maximum applicable motor output complies with 380 V motor ratings as specified in Annex G of IEC 60947-4-1. The rated
output current of the drive output amps must be equal to or more than the motor rated current.
*2 The rated output capacity is calculated with a rated output voltage of 440 V.
To Next Page
