Parameter Details
12
12.2 b: APPLICATION
SIEPCYEUOQ2V01A Q2V Technical Manual 477
■ b5-35: PID In Hi Limit Level
No.
(Hex.)
Name Description
Default
(Range)
b5-35
(01A0)
RUN
PID In Hi Limit Level
Sets the output upper limit for the PID control as a percentage of the Maximum Output
Frequency.
1000.0%
(0.0 - 1000.0%)
A large input value for PID control makes a high output. The drive applies this limit to the negative and positive
domains.
■ b5-36: PID HiHi Limit Level
No.
(Hex.)
Name Description
Default
(Range)
b5-36
(01A1)
PID HiHi Limit Level
Sets the level that triggers Excessive PID Feedback [FbH] as a percentage of the Maximum
Output Frequency.
100%
(0 - 100%)
When the feedback signal increases to more than the level set in b5-36 for the time set in b5-37 [PID HiHi Time],
the drive will detect Excessive PID Feedback [FbH].
■ b5-37: PID HiHi Time
No.
(Hex.)
Name Description
Default
(Range)
b5-37
(01A2)
PID HiHi Time
Sets the length of time that the PID feedback signal must be more than the level set in b5-36 [PID
HiHi Limit Level] to cause Excessive PID Feedback [FbH].
1.0 s
(0.0 - 25.5 s)
■ b5-38: PID SP User Scale for Display
No.
(Hex.)
Name Description
Default
(Range)
b5-38
(01FE)
PID SP User Scale for
Display
Sets the value that the drive sets or shows as the PID setpoint when at the maximum output
frequency.
Determined by b5-20
(1 - 60000)
The drive uses this parameter and b5-39 [PID SP User digits for Display] together.
When b5-20 = 3 [PID Unit Selection = User Units], the drive applies user-set PID setpoint and display units to
these parameters and monitors:
• b5-19 [PID Setpoint Value]
• b5-58 [PID Setpoint 2]
• b5-59 [PID Setpoint 3]
• b5-60 [PID Setpoint 4]
• U5-01 [PID Feedback]
• U5-04 [PID Setpoint]
• U5-99 [PID Setpoint Command]
■ b5-39: PID SP User digits for Display
No.
(Hex.)
Name Description
Default
(Range)
b5-39
(01FF)
PID SP User digits for
Display
Sets the number of digits to set and show the PID setpoint.
Determined by b5-20
(0 - 3)
The drive uses this parameter and b5-38 [PID SP User Scale for Display] together.
When b5-20 = 3 [PID Unit Selection = User Units], the drive applies user-set PID setpoint and display units to
these parameters and monitors:
• b5-19 [PID Setpoint Value]
• b5-58 [PID Setpoint 2]
• b5-59 [PID Setpoint 3]
• b5-60 [PID Setpoint 4]
• U5-01 [PID Feedback]
