Omron Q2V Series User Manual

3.3 Main Circuit Wiring
54 SIEPCYEUOQ2V01A Q2V Technical Manual
Model Terminal
Recommended Gauge
mm
2
Applicable Gauge
mm
2
Wire Stripping
Length
*1
mm
Terminal Screw
Tightening Torque
N∙m (in∙lb)
2042
R/L1, S/L2, T/L3 10 2.5 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 2.5 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 16 4 - 25 18
M5
2.3 - 2.5
(19.8 - 22)
B1, B2 4 2.5 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
10 6 - 16 -
M5
2.0 - 2.5
(17.7 - 22.1)
2056
R/L1, S/L2, T/L3 16 4 - 25 18
M5
2.3 - 2.5
(19.8 - 22)
U/T1, V/T2, W/T3 16 4 - 25 18
M5
2.3 - 2.5
(19.8 - 22)
-, +1, +2 25 6 - 35 18
M5
• ≤ 25 mm
2
2.3 - 2.5
(19.8 - 22)
• 35 mm
2
≤
4.1 - 4.5
(36 - 40)
B1, B2 10 4 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
10 10 - 25 -
M6
5.4 - 6.0
(47.8 - 53.1)
2070
R/L1, S/L2, T/L3 25 6 - 35 20
M6
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 16 6 - 25 20
M6
5 - 5.5
(45 - 49)
-, +1, +2 35 10 - 50 20
M6
5 - 5.5
(45 - 49)
B1, B2 10 4 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
16 10 - 25 -
M6
5.4 - 6.0
(47.8 - 53.1)
2082
R/L1, S/L2, T/L3 35 10 - 50 20
M6
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 25 10 - 35 20
M6
5 - 5.5
(45 - 49)
-, +1, +2 50 16 - 70 20
M6
5 - 5.5
(45 - 49)
B1, B2 16 4 - 16 10
M4
1.5 - 1.7
(13.5 - 15)
16 10 - 25 -
M6
5.4 - 6.0
(47.8 - 53.1)
*1 Remove insulation from the ends of wires to expose the length of wire shown.
*2 If you turn on the internal EMC filter, the leakage current of the drive will be more than 3.5 mA. Use these closed-loop crimp
terminals or equivalent to connect a protective ground wire that has a minimum cross-sectional area of 10 mm
2
(copper wire).
• 8-4NS from JST Mfg. Co., Ltd.
• R8-4S from NICHIFU Co.,Ltd.
