12.7 H: TERMINALS
630 SIEPCYEUOQ2V01A Q2V Technical Manual
■ H7-17: Virtual Out4 Delay Time
No.
(Hex.)
Name Description
Default
(Range)
H7-17
(11AB)
Expert
Virtual Out4 Delay Time
Sets the minimum ON time for virtual digital output 4.
0.1 s
(0.0 - 25.0 s)
■ H7-30: Virtual AIn Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-30
(1177)
Expert
Virtual AIn Select Function
Sets the virtual analog input function.
0
(0 - 32)
■ H7-31: Virtual AIn Gain
No.
(Hex.)
Name Description
Default
(Range)
H7-31
(1178)
RUN
Expert
Virtual AIn Gain
Sets the virtual analog input gain.
100.0%
(-999.9 - 999.9%)
■ H7-32: Virtual AIn Bias
No.
(Hex.)
Name Description
Default
(Range)
H7-32
(1179)
RUN
Expert
Virtual AIn Bias
Sets the virtual analog input bias.
0.0%
(-999.9 - 999.9%)
■ H7-40: Virtual AOut Enable
No.
(Hex.)
Name Description
Default
(Range)
H7-40
(1163)
Virtual AOut Enable
Sets the signal level of the virtual analog output.
1
(1 - 3)
1 : 0 to 100% (Absolute Value)
2 : -100 to 100%
3 : 0 to 100% (Lower Limit at 0)
■ H7-41: Virtual AOut Select Function
No.
(Hex.)
Name Description
Default
(Range)
H7-41
(1164)
Virtual AOut Select
Function
Sets the monitor to be output from the virtual analog output.
102
(0 - 999)
Set the x-xx part of the Ux-xx [Monitor]. For example, set H7-41 = 102 to monitor U1-02 [Output Frequency].
■ H7-42: Virtual AOut Filter Time
No.
(Hex.)
Name Description
Default
(Range)
H7-42
(1165)
Virtual AOut Filter Time
Sets the time constant for a primary filter of the virtual analog output.
0.00 s
(0.00 - 2.00 s)
